Himiway Cobra Electric Mountain Bike

Four-Bar Linkage Suspension & Coil Suspension

Himiway Cobra is the first e-bike on the U.S. market with four-bar linkage suspension technology. The four-bar linkage represents a four-sided polygon: the chain stay, seat stay, rocker, and seat tube. These specialize in absorbing both rear-upward force and vibrations, while the coil suspension ensures front stability. Both suspensions guarantee your safety in the toughest riding conditions

48V 20Ah Samsung/LG Lithium-ion Battery

Himiway Cobra combines the new Samsung/LG battery technology with a 5000mAh single cell capacity in a smaller size but with larger diversity. Compared with 3500mAh cells made of nickel, cobalt, and manganese, this 960Wh battery efficiently improves the range, stability and safety of Himiway bikes. A single charge can last up to 60 miles on pure electric power and 80+ miles with pedal assist. The battery will maintain 80% capacity after 1000 charges.

Specification
Battery 48V 20Ah Samsung/LG lithium battery
Range 60–80 miles
86NM Max Motor Torque
Hub Motor 750W brushless geared hub motor
Total Payload Capacity 400 lb.
Recommended Rider Heights 5′4″ ~ 6′4″
Charger US standard 3.0 A smart charger
Controller 48V/22A
Display LCD display with USB charging
Weight 88 lb.
Pedal Assist Intelligent 0~5 level pedal assist
7 Hours until fully charged

Components
Tires 26″ x 4.8″ CST fat tires
Brake lever Aluminum alloy comfort grip levers with motor cutoff switch
Rear Light Battery-powered bike light
Freewheel Shimano 7 speed gear shift system
Brake Tektro 180mm hydraulic brakes
Chain KMC chain
Stem Promax MA-400 SSABK
Crank 170mm forged alloy
Gearing Shimano- 14-28T BROWN/BK
Front Fork Alloy front suspension fork with lockout and adjustment
Throttle Half-twist throttle
Pedal Alloy pedal with reflectors
Bike Frame 6061 Aluminum frame
Front Light 48V LED light
Saddle SR saddle
Seat Post Diameter 30.9mm, length 300mm
Kickstand Heavy-duty aluminum
Spokes 13 gauge on the front, 12 gauge on the back
